The ideal choice for small form factor devices with high performance demands, Transcend's High Capacity microSD cards are specifically designed for use in digital cameras, DV recorders, mobile phones, and other small devices. To ensure reliability and endurance, these microSD cards are manufactured using brand-name MLC NAND Flash chips and undergo extensive reliability testing at all stages of production.
Features
- RoHS compliant
- Comply with SD File System Specification Ver. 3.0
- Support Copy Protection for Recorded Media (CPRM) for SD-Audio
- Support Speed Class Specification Class 10
- Support auto-standby, power-off and sleep modes
- Built-in Error Correcting Code (ECC) to detect and correct transfer errors
- Manufactured with brand-name MLC NAND Flash chips for extra endurance and stability
Appearance
|
| Dimensions (Max.) |
11 mm x 15 mm x 1 mm (0.43" x 0.59" x 0.04") |
|---|
| Form Factor |
|
|---|
Storage
|
| Flash Type |
|
|---|
| Capacity |
|
|---|
Operating Environment
|
| Operating Voltage |
|
|---|
| Drop Test |
|
|---|
| Operating Temperature |
-25°C (-13°F) ~ 85°C (185°F) |
|---|
| Storage Temperature |
-40°C (-40°F) ~ 85°C (185°F) |
|---|
| Humidity |
0% ~ 95% |
|---|
| Shock |
- Acceleration: 490 m/s² (standard holding time: 11 ms, semi-sine wave, velocity change: 3.44 m/s)
|
|---|
| Vibration (Operating) |
20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency) |
|---|
Power
|
| Power Consumption (Max.) |
0.72 watt(s) |
|---|
Performance
|
| Read Speed (Max.) |
24 MB/s |
|---|
| Write Speed (Max.) |
22 MB/s |
|---|
| Terabytes Written (Max.) |
60 TB |
|---|
| Note |
- Speed may vary due to host hardware, software, usage, and storage capacity.
|
|---|
