Model number

RR-H103-22PB-R1

CPU Socket

Intel®
LGA 2066/1156/1155/1150/775

AMD
FM2+/FM2/FM1/AM3+/AM3/AM2

Dimensions (LxWxH)

108(L) x 89.5(W) x 138.5(H) mm

Heat Sink Dimensions (LxWxH)

96(L) x 61(W) x 138.5(H) mm

Heat Sink Material

Aluminum (Fins)
Copper (Heatpipes)

Heat Sink Weight

500g

Heat Pipes Diameter

ø 6mm

Fan

Fan Dimensions (LxWxH)

92(L) x 92(W) x 25(H) mm

Fan Speed

800-2,200 RPM ± 10%

Fan Airflow

15.7-43.1 CFM ± 10%

Fan Air Pressure

0.35-2.63 mmH2O ± 10%

Fan Life Expectancy

40,000 hrs

Fan Noise Level (dBA)

17-30 dBA

Fan Bearing Type

Long Life Sleeve Bearing

Fan Connector

4-Pin (PWM)

Fan Rated Voltage

12 VDC

Fan Rated Current

0.15 A

Fan Power Consumption

1.8 W

Fan Weight

80g

Warranty

1 Year
